68,000.00 / piece( + 18% GST applicable)
| Business Type | Manufacturer, Exporter, Supplier |
| Country of Origin | India |
| Warranty | 5years, 5 Year |
| Weight | 100-500kg, 500-1000kg |
| Click to view more | |
Product Details
Type
Gearless Traction Elevator
Loading Capacity
400-600Kg
Capacity
408 Kg,6 Passengers
Voltage
380V
Certification
CE Certified, ISO 9001:2008
Application
Commercial, Industrial, Residential
Power
1-2kw, 2-4kw, 4-6kw
Color
Green And Yellow
Elevator Type
Gearless Elevator Traction Machine
Driven Type
Electric
Brand Name
Mont Drive
Power Source
Electric
Material
Cast Iron
Brand - Mont Drive
Colour- Black and Yellow
Encoder Warranty
3 Year
Poles
24
Product Code
JDE 24P SERIES
Port
by road, by sea and by air
Payment Terms
L/C, T/T, Other
Delivery Time
1 to 5 Days
Packaging Details
PACKING LIST :-
• Gearless Machine
• Break Releaser
• Break Releaser Wire
• Encoder Wire
• 4mm Three-phase Wire
• Gearless Machine
• Break Releaser
• Break Releaser Wire
• Encoder Wire
• 4mm Three-phase Wire
We are a leading manufacturer of Gearless Elevator Traction Machines. Our Manufacturing unit is located in Mayapuri Industrial Area, Phase-2 , New Delhi
Our Product Specifications:-
Brand Name:- MONT DRIVE
Encoder:- HEIDENHAIN ERN 1387
Pole:- 24 Poles
5 years Warranty of the Machine alongwith 3-year warranty of encoder
Specifications
| Material | Cast Iron |
| Usage/Application | Lifts/ Elevators |
| Brake Voltage | 110V DC |
| Voltage | 380V Three Phase |
| Brand | Mont Drive |
| Sheave diameter | 320 mm |
| poles | 24 Poles |
| Country of Origin | Made in India |
| Frequency | 24 HZ |
| Features | Easy to install, Low weight, Gearles |
| Color | Grey |
| Warranty | 4 Years |
| Weight | Approx. 165 Kgs |
| Duty Load | 544 kgs. |
| IP Degree of Protection | IP 41 |
| Passenger Capacity | 8 Passengers |
| Encoder | Heidenhain (1387) / Innovance |
| Current | 9 Amp |
| Torque | 250 NM |
